Torchlight - Deep Learning Framework from Scratch

Published: July 02, 2026

The best way to understand deep learning is to build it. Not a wrapper around TensorFlow, not a thin PyTorch clone — a real framework, where you can read every line that makes backpropagation, GPU kernels and a language model work.

That is what torchlight is: a lightweight, from-scratch deep learning framework, CPU-first, numpy-backed, with an optional numba-CUDA accelerator — and with three real end-to-end projects (sentiment analysis, English→French translation, and a miniature GPT on Shakespeare) shipped on top of it.

Repository: https://github.com/ajeetkbhardwaj/torchlight Documentation: https://ajeetkbhardwaj.github.io/torchlight/

Why build a framework from scratch?

Every serious AI engineer eventually hits the point where a framework feels like a black box. Gradients appear “magically”; a nn.Module does things you don’t fully trust; loss.backward() might as well be a prayer.

Torchlight was built to replace that feeling with certainty. Its design goals are deliberately modest:

A tiny surface area. The entire compute layer is four primitives (map, zip, reduce, matmul) plus a couple of fused kernels. If you understand those, you understand the whole engine.
Numerical correctness you can assert. Every operation ships with a finite-difference gradcheck in the test suite — the math isn’t “trusted”, it is proven.
CPU-first and dependency-light. A single hard dependency: numpy. No compiled extensions, no GPU required to get started.
Small-scale LLM experiments. Big enough to train a real sequence model, small enough to read overnight.

The core bet: tensors all the way down

Torchlight is a study in reduction. High-level concepts — layers, losses, optimizers, datasets — are all bookkeeping on top of one object: the Tensor.

The whole system, in one diagram:

flowchart TB
    subgraph User["Your code"]
        A1["tensor ops / autograd"]; A2["nn modules"]; A3["optimizers"]
        A4["data loaders"]; A5["jit trace / persistence"]
    end
    subgraph API["torchlight public API"]
        B["Tensor / factories"]; C["Module / Parameter tree"]
        D["Optimizer / Scheduler"]; E["Dataset / DataLoader"]
        F["trace / GraphTape / save-load"]
    end
    subgraph Core["Core engine"]
        G["Autograd: Function · Context · History"]
        H["TensorData: flat float32 storage + shape/strides"]
    end
    subgraph Be["Backend layer"]
        I["map / zip / reduce / matmul + fused softmax · layernorm"]
        J["CPUBackend — numpy"]; K["NumbaBackend — numba CPU-JIT"]
        L["CudaBackend — numba-cuda or ctypes .so"]
    end
    subgraph HW["Hardware"]; M["CPU"]; N["NVIDIA GPU"]; end
    A1 --> B; A2 --> C; A3 --> D; A4 --> E; A5 --> F
    B --> G; C --> G; E --> B; G --> H; H --> I
    I --> J; I --> K; I --> L; J --> M; K --> M; L --> N

The layers, bottom-up:

1. Tensors and `TensorData`

A tensor’s real data lives in a TensorData: a flat one-dimensional float32 buffer, plus shape and strides. Views, transposes and broadcasts change strides — never the buffer. That one decision makes x.T @ y, slicing, and broadcasting all zero-copy and boringly fast.

import torchlight as tl

x = tl.tensor([[1.0, 2.0], [3.0, 4.0]], requires_grad=True)
t = x.T          # strided view, no copy
m = x @ t        # matmul through the backend

2. The autograd engine

Reverse-mode automatic differentiation over a dynamic graph. Each forward op is a Function that records a History node on its output: the function, the saved inputs, and a Context for forward-pass values. backward() then walks the graph in reverse topological order:

y = (x ** 2).sum()
y.backward()
print(x.grad.to_numpy())   # [2.0, 4.0, 6.0]

The whole engine — Function, Context, History, the topo-sort and backpropagation — lives in a few hundred readable lines under src/torchlight/autograd/.

3. Modules, parameters, optimizers

nn.Module intercepts attribute assignment. A Parameter lands in _parameters; a child Module in _modules. parameters() walks the tree recursively, so Adam and the checkpoint saver see every trainable tensor with zero extra registration. On top of that: Linear, Embedding, Conv1d/2d, LayerNorm/BatchNorm, dropout, activations, pooling, losses, plus SGD (momentum/nesterov), Adam, and AdamW.

from torchlight.nn import Sequential, Linear, ReLU
from torchlight.optim import Adam

model = Sequential(Linear(2, 16), ReLU(), Linear(16, 2))
opt = Adam(model.parameters(), lr=1e-3)

4. The six-primitive backend layer

All compute funnels through map / zip / reduce / matmul (+ fused softmax/LayerNorm). That contract is small enough to be reimplemented three times — numpy on CPU, numba JIT, numba-CUDA on an NVIDIA GPU — so device parity is guaranteed by construction. TORCHLIGHT_DEVICE=cuda flips the switch; a missing driver produces a clear error instead of a silent fallback.

5. Data, tracing, persistence

Dataset / TensorDataset / DataLoader with shuffling and batching, plus a synthetic-problem zoo (Xor, Circle, Spiral, …) for smoke tests.
jit.trace records a forward pass as an op tape, then count_ops() or replays it on new inputs without rebuilding the autograd graph.
save_state/load_state persist any model to a .npz checkpoint.

Proof it works: real projects on real data

A framework is only as good as what you can build with it. Torchlight ships three complete projects, each documented from first principles, maths included:

1. Sentiment classifier — 3000 real IMDb/Amazon/Yelp reviews through an embedding → masked-mean pooling → MLP, trained end to end. Article: https://ajeetkbhardwaj.github.io/torchlight/projects/sentiment-classifier/

2. English → French translation — a GRU encoder-decoder with Luong attention, teacher forcing, and greedy decoding on ~102k real Tatoeba pairs. This one taught me something a library would have hidden: the off-by-one in targets. Decoder input starts with SOS; the training target must end with EOS. Get that wrong and the model happily predicts padding forever.

3. A miniature GPT — a real decoder-only transformer (causal self-attention, multi-head, LayerNorm + residuals) trained character-by-character on tiny Shakespeare, complete with temperature sampling. Every attention head is hand-built from Q, K, V — no Attention module exists to lean on.

Each project runs as train.py → saves out/*.npz → post.py reloads, evaluates (accuracy/F1, BLEU, perplexity) and plots. The full loop of a research project, end to end, in one directory.

The sklearn examples show the same framework dropping into classic ML — an MLP with BatchNorm/Dropout/cosine annealing on breast cancer, a CNN on handwritten digits, and a class-conditioned autoencoder. Article: https://ajeetkbhardwaj.github.io/torchlight/examples/sklearn-classifier/

Start with the tensor tutorial to see exactly what the codebase does: https://ajeetkbhardwaj.github.io/torchlight/tutorials/01-tensors/

Quality you can run

A from-scratch framework that can’t be trusted is a liability. Torchlight addresses that with:

260 passing tests, including finite-difference gradchecks on every op,
CPU/numba/CUDA op parity locked by tests,
a full CI suite on GitHub Actions (Python 3.10–3.12) and CD that builds the docs and deploys them to GitHub Pages on every push to main,
sedate numeric stability: softmax, log-softmax and cross-entropy are written to survive hostile input (e.g. exp(x - max(x))).

Articles, docs, and where all the maths lives

The documentation is the heart of the project. Every page explains the model from first principles, with the maths rendered on the page:

System design (this entire architecture, with diagrams) — the docs home,
a tutorial series (tensors → autograd → nn → data/optimizers → backends → jit/persistence → real datasets),
one page per project and one per example, each deriving its formulas ($\sigma(z)=\frac{1}{1+e^{-z}}$, attention scores, GRU gates, …) and then mapping them onto the code.

Exactly the kind of article you are reading is what got me from “that seems intimidating” to “I can build this.”

What’s next

more fused kernels and tighter parity between the numpy and CUDA paths,
higher-capacity experiments (a slightly larger GPT, maybe a byte-pair tokenizer),
publishing the package to PyPI once the name situation is settled.
